VL Audio Viva 715D

VL-AUDIO VIVA 715D TECHNICAL SPECIFICATIONS

• Acoustical specifications Frequency Response: 45 Hz – 20000 Hz
• Max SPL @ 1m: 130 dB
• Horizontal coverage angle: 90°
• Vertical coverage angle: 60°

Transducers

• Compression Driver: 1.0”, 1.50” v.c
• Woofer: 15”, 3” v.c

Input/Output section

• Input signal: Balance/Unbalance
• Input connectors: XLR, Jack
• Output connectors: XLR
• Input sensitivity: -2 dBu/+4 dBu

Processor section

• Mic. Input Sensitivity: -32 dBu
• Crossover Frequencies: 1800 Hz
• Protections: Thermal, RMS
• Limiter: Soft Limiter
• Controls: Volume, Boost, Mic/Line

Power section

• Total Power: 1400 W Peak, 700 W RMS
• High frequencies: 200 W Peak, 100 W RMS
• Low frequencies: 1200 W Peak, 600 W RMS
• Cooling: Convection
• Connections: VDE

Standard compliance

• CE marking: Yes

Physical specifications

• Cabinet/Case Material: PP Composite
• Hardware: 2 x M10
• Handles: 1 Top, 2 Side
• Pole mount/Cap: Yes
• Grille: Steel
• Color: Black

Size

• Height: 687 mm / 27.1 inches
• Width: 420 mm / 16.5 inches
• Depth: 390 mm / 15.3 inches
• Weight: 20 kg / 44.09 lbs
